ReaXus Dual Piston Pumps
ReaXus CP Class
סדרת משאבות בוכנה דו-ראשיות מבית חברת ISCO, בעלות זרימה חיובית עם בקרת לחץ קבוע, מגיע ללחצים של עד 25,000 psi.
חומרי המבנה הם stainless steel עם אפשרות ל- Hastelloy עם ראשי משאבה מצופים (מעיל) לתהליכים בטמפרטורה מבוקרת.
המשאבה מתאימה לאריזת קולונות לכרומטוגרפיה נוזלית (עמודות 4.6 מ"מ) ולתהליכים רבים נוספים.
למשאבה מנגנון המתאים באופן אוטומטי את זרימת הממס כדי לשמור על לחץ קבוע.
בסדרת משאבות CP (Constant Pressure) שלושה דגמים הנבדלים בזרימות השונות ובלחצים השונים: 5 מל/דקה, 24 מל/דקה ו- 100 מל/דקה.
ניתן לרכוש בנפרד מערכת לאריזת קולונות מבית Teledyne (Pack-in-a-Box).
ReaXus CP Class – Constant Pressure, positive displacement, dual-headed piston pumps with constant pressure control, covering a wide range of flows, with pressures up to 25,000 psi.
Standard fluid path material is Stainless Steel. Other available features include Hastelloy fluid path with jacketed pump heads for temperature controlled processes.
The CP Class pumps are widely used for Liquid Chromatography Column packing for 4.6 mm columns, as well as many process applications. The constant-pressure feedback loop automatically adjusts solvent flow to maintain constant system pressure.
Available separately is the Teledyne SSI Column Packing System: “Pack-in-a-Box”.
With 5 mL/min, 24 mL/min, and 100 mL/min versions, the CP Class will meet most Liquid Chromatography Column packing and process needs.
מידע נוסף
יישומים
המשאבות מסדרה CP מיועדות לאריזת קולונות 4.6 מ"מ לכרומטוגרפיה נוזלית ולתהליכים רבים אחרים הדורשים לחץ גבוה וקבוע.
למשאבות בסדרה ישנו מנגנון המתאים באופן אוטומטי את זרימת הממס כדי לשמור על לחץ קבוע ולוח מקשים אינטראקטיבי ומצב בקרת מחשב מלא באמצעות יציאות RS-232 ו- Micro USB 2.0.
ניתן לרכוש מערכת משלימה לאריזת קולונות LC:
Teledyne SSI Column Packing System (called Pack-in-a-Box).
תכונות המכשיר
Flow Rate Range and Max. Pressure Ratings
0.001-12.000 mL/min (18,000 psi)
0.01-24.00 mL/min (10,000 psi)
0.1-100.0 mL/min (4,000 psi)
Control
RS-232, Micro USB, Run/Stop, Analog (0-10V, 4-20mA)
