Advanced Flash chromatography system
+CombiFlash NextGen 300
Advanced Flash chromatography system
CombiFlash
+NextGen 300
+CombiFlash Nextgen 300
by Teledyne LABS
A fully featured
Flash Chromatography System
designed for purification tasks
The most advanced Flash chromatography system in the market
לקבלת ייעוץ ורכישה של קולונות
השאירו כאן את הפרטים:
+CombiFlash NextGen 300
A fully featured flash chromatography system designed for purification tasks. Here are the key features:
- Flow Rate Range: From 1 to 300 mL/min at operating pressures up to 300 psi (20 bar).
- Injection Valve: Equipped with a solid load injection valve, which can be bypassed for liquid injections.
- RFID Technology: Automatically reads the size and type of RediSep or RediSep Gold® column being used, setting default gradient and flow rate.
- Focus Gradient Generator: Included for predictive method development.
- Safety Features: Active solvent and waste level sensing, column air purge, and more.
- Compact Design: Takes up minimal lab space.
לפרטים נוספים והצעת מחיר, מלא את הפרטים למטה
מידע נוסף
תכונות המכשיר
| Flow rates: | 1-300 ml/minute | טווח קצב זרימה |
| Highest pressure: | 300psi (20bar) | לחץ מקסימלי |
| Column size: | 4-750 gr | מידות קולונות |
| Sample size: | 10 mg – 150 gr | מידות דגימות |
| Touch screen size: | 12 inch (30.5 cm) | גודל מסך מגע |
| 15 inch (- 38.1 cm) | ||
| Device dimentions: | 66X36X43 cm | מידות המכשיר |
Combiflash NextGen 300+ Full Demonstration
Flash Chromatography with CombiFlash — What It Is and How Systems Scale (FAQ)
What is flash chromatography and when should I use a CombiFlash system?
Flash chromatography is automated, low-to-medium-pressure purification used to isolate milligram-to-kilogram quantities of a target compound from a reaction mixture. A CombiFlash system runs a solvent gradient through a disposable or reusable silica/C18 cartridge with inline UV (and optional ELSD/mass) detection and automatic fraction collection — far faster and more reproducible than manual column chromatography, making it the standard tool in medicinal, synthetic and natural-product chemistry.
How do CombiFlash NextGen systems scale from milligrams to kilograms?
The same gradient method scales by changing cartridge size and flow. Typical loading spans a few milligrams on small RediSep cartridges up to hundreds of grams (kilogram-scale campaigns) on large columns, so a method developed at screening scale transfers to production without re-optimisation. BioAnalytics supplies the Teledyne ISCO CombiFlash range, RediSep media, method support and local service in Israel.
Need help selecting or a quote?
Our application team supports selection, method transfer, service and ISO/IEC 17025 calibration in one place.
Request a quote
Our application team supports selection, method transfer, service and ISO/IEC 17025 calibration in one place.
Request a quote
Written and reviewed by Dani Shahar and the BioAnalytics Application Team · ISO/IEC 17025:2017 accredited calibration lab (PJLA · ILAC-MRA)
